Shaders are small GPU programs, but they do not all run at the same time or on the same kind of data. The biggest early learning jump is understanding that vertex shaders and fragment shaders solve different problems at different frequencies. A vertex shader runs per vertex, while a fragment shader runs per fragment (roughly per covered pixel sample). That one difference explains most behavior, performance cost, and visual results you see in real-time rendering.

This article builds a concrete model of where each shader stage runs, what data it reads, and what data it produces. The focus is the vertex vs fragment split, then we place geometry, tessellation, and compute shaders in context.

Pipeline Position and Data Flow

In a standard rasterization pipeline, vertices enter first, then become primitives, then become fragments, then become final framebuffer pixels. So the most important question is: what does each stage receive as input?

• Vertex shader input: one vertex at a time (position, normal, UV, tangents, custom attributes)
• Vertex shader output: transformed clip-space position and varyings to be interpolated
• Fragment shader input: interpolated varyings for each fragment plus textures, uniforms, and material parameters
• Fragment shader output: one or more color/depth values written to render targets

Use this stage explorer and click different stages. It highlights why vertex and fragment are always part of the main graphics path, while some other stages are optional.

A practical way to remember this is to track where count explodes. A mesh may have tens of thousands of vertices, but a full-screen draw can touch millions of fragments. Because fragment count is often much larger, expensive math in fragment shaders usually costs more frame time than the same math in vertex shaders.

Vertex Shader Responsibilities

A vertex shader is usually responsible for geometric placement. Its most common job is multiplying each vertex position by model, view, and projection matrices. It can also prepare values for later stages, such as world-space normals, texture coordinates, or custom effect data.

Mathematically, the canonical transform looks like:

$$\text{clipPos} = P\,V\,M\,[x,y,z,1]^T$$

The important detail is not the formula itself, but the execution rate. If your model has 20,000 vertices, this shader runs around 20,000 times for that draw call. It does not run for every pixel on screen.

In the playground below, the gray triangle is the incoming vertex data and the blue triangle is the transformed output after a simplified transform chain. Change rotation, scale, and translation and watch how output vertex positions move in normalized device space.

When this stage is misunderstood, beginners often try to do pixel-level effects in a vertex shader. That usually creates blocky or unstable results because vertex shader outputs are only known at vertices and then interpolated across each triangle. Interpolation is useful, but it is not equivalent to true per-fragment computation.

Fragment Shader Responsibilities

After primitives are rasterized, the GPU generates fragments. Each fragment has interpolated varyings from the vertex stage. Now the fragment shader decides the visible surface appearance: base color, texture detail, lighting response, transparency logic, and sometimes whether a fragment should be discarded.

This stage is where materials become image detail. If you sample a texture, combine normal maps, compute BRDF terms, apply fog, and blend layers, that work usually happens here.

In the interactive example, each fragment inside a triangle receives interpolated color and UV data. Then a shader-style process blends texture and vertex color, applies a simple Lambert lighting term, and can drop fragments below a threshold (similar to alpha-cutout logic).

Notice what changes smoothly across the triangle: not the original vertex values directly, but interpolated values. That interpolation step is one of the core reasons the vertex and fragment stages are paired. The vertex stage prepares data endpoints, and the fragment stage uses continuous values between endpoints to compute final appearance.

Direct Vertex vs Fragment Comparison

The fastest way to compare these stages is to ask the same four questions for both.

1. How often does it run? Vertex shader: once per vertex. Fragment shader: once per fragment.

2. What is the main purpose? Vertex shader: geometric transformation and varying setup. Fragment shader: final shading and output color/depth.

3. What data dominates its input? Vertex shader: mesh attributes plus transform uniforms. Fragment shader: interpolated varyings, textures, lights, material uniforms.

4. What performance pattern is typical? Vertex shader: scales with geometry complexity. Fragment shader: scales with screen coverage and overdraw.

These differences imply practical optimization rules. If an effect can be approximated with per-vertex math and interpolation, it can be cheaper. If accuracy must be pixel-precise (specular response, normal mapping, fine procedural detail), it belongs in the fragment stage even if cost increases.

Common Mistakes in Stage Selection

One frequent error is pushing too much logic into fragments without considering coverage. A full-screen post-effect at 4K can execute many millions of shader invocations per frame. Another error is pushing appearance logic too early into vertices and then wondering why detail collapses on large triangles.

A simple decision process helps:

1. Does this computation define object placement? Put it in vertex.
2. Does it define pixel-level appearance? Put it in fragment.
3. Does it need neighboring pixel information from already-rendered data? Often this means a later post-process pass, possibly compute.

That process is not perfect, but it avoids most architectural mistakes in real-time rendering code.

Other Shader Types in Context

Geometry Shaders

Geometry shaders run per primitive after the vertex stage. They can emit new primitives, so they are useful for specific effects like layered shadow map outputs or line expansion. However, they are often avoided in performance-critical paths because they can become a throughput bottleneck. Many modern engines prefer alternatives such as instancing, mesh shaders (on supported APIs), or compute-driven generation.

Tessellation Shaders

Tessellation is split into control and evaluation stages. It subdivides patch primitives to add geometric density on the GPU. This can improve curved surfaces and displacement mapping when screen-space detail demands it. The tradeoff is increased complexity and hardware/API constraints, so many teams use it selectively.

Compute Shaders

Compute shaders are not tied to rasterization. They execute general-purpose GPU kernels over thread groups and are widely used for simulation, culling, particle updates, clustered lighting preparation, denoising, and post-processing. In modern renderers, compute often cooperates with traditional graphics passes rather than replacing them.

A useful mental map is:

• Vertex + Fragment: core raster graphics path
• Geometry + Tessellation: optional geometry amplification/refinement stages
• Compute: general parallel processing path that can feed or consume rendering data

Building Intuition for Real Projects

When debugging rendering issues, identify the stage boundary where wrong data first appears. If transformed positions are wrong before rasterization, inspect vertex logic. If geometry looks right but color/lighting is wrong, inspect fragment logic. If topology or subdivision is wrong, inspect geometry/tessellation stages. If preprocessing buffers are wrong, inspect compute kernels.

You can also profile by stage intent. High vertex cost often tracks dense meshes or heavy skinning. High fragment cost often tracks large screen coverage, expensive material math, or overdraw from transparent layers. That split gives immediate direction for optimization experiments.

Summary

Vertex and fragment shaders are different because they run on different units of work. Vertex shaders process mesh points and prepare interpolated data. Fragment shaders process rasterized fragments and compute final appearance.

If you keep that execution model in mind, most pipeline decisions become clearer:

• Place-space math and varying preparation in vertex shaders.
• Pixel-accurate material and lighting logic in fragment shaders.
• Use geometry and tessellation only when their specific capabilities are needed.
• Use compute for general GPU tasks outside strict raster flow.

That model scales from simple demos to production renderers and makes shader code easier to reason about, optimize, and debug.
